Assembled hose

Besides the unbraided hose, and braided hose without fittings,we supply assemble hose as well with different connection types.

*BSPT Taper Male,

*BSP Cone Female with swivel nut

*BSP Flat face Female with Swivel nut

*DIN2828 camlock couplings

*NPT Fittings

*Flange connections, the flange codes can be DIN2500, ANSI B 16.5, JIS B2210-84.

Joint type   Mame Sample  Nominal Dia  Code  Remark
hexagon union straight female DN6-DN50 RL1 Sealed with washer
conical joint
hexagon straight female
DN6-DN50 RL2 Sealed with metal wire high temperature proof
female swivel DN6-DN50 RL3 Sealed with metal wire high temperature proof
hexagon nipple straight male DN6-DN50 RL4 Sealed with metal wire high temperature proof
hexagon union straight male DN6-DN50 RL5 high temperature proof,easy assemble
hexagon nipple tapered male DN6-DN50 RL6 high temperature proof,easy assemble
Union conical female DN6-DN50 RL7 high temperature proof,easy assemble
union conical with swivel female DN6-DN50 RL8 high temperature proof,easy assemble
Union DN6-DN80 RL9 high temperature proof,easy assemble
Welding end  DN6-DN400 RJ Permanent joint
    Download the catalogue in PDF
please click
