Flexible Metal Hose

Standard flexible metal hose

*Stainless steel annular formed corrugated flexible metal hose with a single layer of sus304 stainless steel wire braid.

*The hose is available directly braided.

*Available in 3/8" to 16" diameters

*With available double sus304 wire braid for higher working pressures.

*Mill run lengths of 7-8mtrs.

*This hose is available as directly braided hose single or double layers of sus304 wire braids.

*Unbraided hose available

Standard Flexible Hoses
DN	Corrugated hoses							Single Braid		Double Braid
	ID		OD		Pitch Distance		Thickness	Working Press.	Test Press.	Working Press.	Test Press.
	ID		OD		Pitch Distance		Thickness	Working Press.	Test Press.	Working Press.	Test Press.
	I.D. (mm)	Devi. (mm)	O.D. (mm)	Devi. (mm)	I(mm)	Devi. (mm)	S(mm)	Bar	Bar	Bar	Bar
8	8	±0.10	12..3	±0.10	2.9±0.2	±0.02	0.2	80	120	140	210
10	10	±0.10	14.6	±0.10	2.8	±0.01	0.2	90	135	140	200
12	12	±0.10	18	±0.10	2.8	±0.02	0.2	80	125	120	180
15	14.4	±0.10	21.5	±0.10	3.5	±1	0.3	80	125	120	180
20	20	±0.10	27	±0.10	4.5	±1	0.28	60	90	80	100
25	25	±0.10	32.5	±0.10	5	±1	0.28	60	90	80	100
32	32	±0.10	40	±0.10	5	±1	0.28	50	80	70	90
40	40	±0.10	50	±0.10	6	±1	0.28	50	80	70	90
50	50	±0.10	63	±0.10	6	±1	0.3	40	70	60	80
65	65	±0.10	81	±0.10	7	±1	0.4	40	70	60	80
80	80	±0.10	98	±0.10	10	±1	0.4	30	60	50	70
100	100	±0.10	120	±0.10	11.5	±1	0.4	16	30	30	50
125	125	±0.10	150	±0.10	13	±1	0.5	16	30	30	50
150	150	±0.10	180	±0.10	14	±1	0.5	16	30	30	50
200	200	±0.10	230	±0.10	17	±1	0.6	16	30	30	50
250	250	±0.10	280	±0.10	27	±1	0.8	10	20	20	40
300	300	±0.10	340	±0.10	28	±1	0.8	8	16	16	30
