Flexible Smooth Bore PTFE Hose/ Tube/ Pipe

The pipe has changed the characteristics that the pipe can not be bent by special processing methods. It can be used to connect the lower graphite and ceramic glass pipes, and can be used as the feeding and discharging pipe for tank trucks, tanks, containers or reaction still. It can be used for pipe misalignment or to balance pipe displacements, dimensional changes caused by climate or other reasons, or to eliminate high-frequency mechanical vibrations. Can also be used in special occasions such as tubular reactor or heat exchanger.

NO.	Specification	ID (mm)	OD (mm)	Thickness (mm)	Working Pressure (bar)	Burst Pressure (bar)
1	1/8	3.5	6.6	1	326	1007.76
2	3/16	4.8	8	0.85	247	740.52
3	1/4	6.4	9.2	0.85	214.2	666.06
4	5/16	8	11	0.85	191.76	598.74
5	3/8	9.7	12.8	0.85	188.7	567.12
6	1/2	12.7	15.9	1	156	470.22
7	5/8	16	19.2	1	129.54	389.64
8	3/4	19	22.7	1.2	79.56	274.38
9	7/8	22.2	26	1.2	61.2	198.9
10	1	25	29.3	1.5	40.8	156.06
11	2	50	55.6	2	30.6	122.4

Smooth Bore PTFE Hose

The Model type PTFE Hose is a smooth bore PTFE hose with a stainless steel braiding, available up to 1-1/4" diameters. The diameters listed reflect nominal sizing.
It is lightweight, and handles a very broad range of chemicals at relatively high temperatures and pressures, and will not deteriorate in service. It is used in countless tough industrial applications where continual large bending is not required. Commonly provided with JIC, NPT or many other fittings.
Also available with a convoluted PTFE core for tighter bends

Corrugated PTFE Hose

The Model type PTFE Hose is a convoluted PTFE hose with a stainless steel braiding, available up to 4" diameters.The convolutions provide a far tighter bend radius than most smooth bore alternatives.It is lightweight, and handles a very broad range of chemicals at relatively high temperatures and pressures, including full vacuum.
It is used in countless tough industrial applications where a smooth bore is not required. Also available in conductive PTFE.
Commonly provided with JIC, NPT or many other fittings.
